ATORN indexable insert SNMG 120404-FM1 APM20T-1

ATORN indexable insert SNMG 120404-FM1 APM20T-1

ATORN indexable insert SNMG 120404-FM1 APM20T-1
Item no: 1018582 814

Online price:

Available in 6-8 working days.

Notes
Indexable insert SNMG 120404-FM1 APM20T-1

Brand: ATORN
Shape of indexable insert ISO: S
Clearance angle of indexable insert ISO: N
Tolerance class of indexable insert ISO: M
Indexable insert type ISO: G
Size of indexable insert ISO: 12
Thickness of indexable insert ISO: 04
Corner radius of indexable insert ISO: 04
Carbide type area ISO: M
Machining conditions for indexable insert: Good
Carbide type ISO: M20
Carbide type: APM20T-1
ISO-Code Rotating: SNMG 120404
min./max. ap: 1-4 mm
f min./max.: 0.1-0.55 mm/U
f min.: 0,1 mm/r
max. f: 0,55 mm/r
max. ap: 4 mm
min. ap: 1 mm
Chip breaker code: FM1
Min./max. Vc in stainless steel: 90-240 m/min
Min./max. Vc in special alloys: 20-160 m/min

ATORN-No.: 12350579

EAN no.: 4066107026981

Product Datasheet Datasheet cutting values
