ATORN screw tap HSSE vap. B 371 0° M4 0.7 mm ISO2 D 3xD CNC UNI

ATORN screw tap HSSE vap. B 371 0° M4 0.7 mm ISO2 D 3xD CNC UNI

ATORN screw tap HSSE vap. B 371 0° M4 0.7 mm ISO2 D 3xD CNC UNI
Item no: 1014346 104

Online price:

Available for immediate delivery

Application
For producing metric threads on CNC machines or conventional machines in through holes in the steel, stainless steel, non-ferrous metals and cast iron material groups up to a strength of 1000 N/mm².

Execution
Structural dimensions in accordance with: DIN 371 = reinforced shank (up to M10), DIN 376 = over-long shank (from M12)

Advantage
  • Universal use for maximum flexibility in use
  • Innovative cutter geometry ensures high process reliability even in difficult machining conditions


Brand: ATORN
Material to be processed: Universal use
Thread type: Metric thread
Thread type x nominal diameter: M4
Tolerance of screw taps (Tol.): ISO 2 (6H)
Hole type: Clearance hole ≤ 3xD
Lead angle shape: B
Length: 63 mm
Cutting material: HSSE
Surface: Vaporised
Pitch: 0,7 mm
Twist angle: 0°
DIN: 371
Shank diameter: 4,5 mm
Application type/machine type: CNC | Conventional
Core hole diameter: 3,3 mm
Type: UNI 40 Control
Coolant supply: External
Shank square: 3,4 mm
Cutting speed (steel 1000) suitability (ISO P 1000 N/mm²): 1
Cutting speed (steel 1300) suitability (ISO P 1300 N/mm²): 2
Overall stainless steel suitability (ISO M): 1
fitness not iron total (ISO N): 2
fitness Titan/Nickel/Super total (ISO S): 3
Cutting speed (cast) suitability (ISO K): 1
Cutting speed (hard 55) suitability (ISO H 55HRC): 3
Cutting speed (hard 65) suitability (ISO H 65HRC): 3

ATORN-No.: 11290822

EAN no.: 4050293380095

Product Datasheet Datasheet cutting values
Versions
loading
Keywords:

[Text nicht gefunden]

  • ATORN hand tap set HSS A/D/C 352 0° M5 0.8 mm ISO2 D/S 3xD
  •
    ATORN SC radius cutter diameter 4.0 x 8 x 20 x 50 mm T=4 RT65
    53,90 €
  • ATORN twist drill bit set N HSS DIN 338 1.0-5.9 mm 0.1 in box
  •
    ATORN SC mini radius cutter long diameter 4.0 x 8 x 28 x 75 mm T=2 RT65
  •
    ATORN screw tap HSSE vap. B 371 0° M5 0.8 mm ISO2 D 3xD CNC UNI
  •
    ATORN screw tap HSSE B 376 0° M5 0.8 mm ISO2 D 3xD CNC P
  •
    ATORN countersink, 90°, HSS-TiNAIO x T=3, 5.0 x 40 mm, DIN 335 shape C
  •
    ATORN screw tap HSSE-PM ULTRA HL C 374 50° MF12x1.5 ISO2 2.5xD CNC
    79,04 €
  • ATORN hand tap set HSSE A/D/C 352 0° M3 0.5 mm ISO2 D/S 3xD
    61,07 €
  • ATORN screw tap HSSE vap. B 371 0° M3 0.5 mm ISO2 D 3xD CNC UNI
    11,17 €
  • ATORN measuring instrument set in case
  •
