ATORN end mill PM TiAlN D844B K, diameter 14.0 mm

ATORN end mill PM TiAlN D844B K, diameter 14.0 mm

ATORN end mill PM TiAlN D844B K, diameter 14.0 mm
Item no: 1016272 114

Online price:

Available in 11-13 working days.

Application
Roughing cutter for universal machining.

Execution
  • HSSE PM
  • HR - fine roughing teeth
  • Centre cutting
  • Straight shank according to DIN 1835 B
  • TiAIN-coating for maximum service life
  • Also for dry milling with compressed air
  • Twist angle 35°


Brand: ATORN
Cutting material: HSSE-PM
Surface: TiAlN
Type: HR
Number of cutting edges (Z): 4 PCS
Twist angle: 35°
Edge protection chamfer length: 0,2 mm
Tool holding device: HB parallel shank
Construction length: Normal
Cutting edge diameter: 14 mm
Cutting edge length: 26 mm
Length: 83 mm
Shank diameter: 12 mm
fz steel 700: 0,083 mm

ATORN-No.: 11650034

EAN no.: 4050293192285

Product Datasheet Datasheet cutting values
