Maschinen-Gewindebohrer Enorm 2-Z-X-IKZ-PM-GLT-1 M24-6HX

Maschinen-Gewindebohrer Enorm 2-Z-X-IKZ-PM-GLT-1 M24-6HX

Maschinen-Gewindebohrer Enorm 2-Z-X-IKZ-PM-GLT-1 M24-6HX
Item no: 1014415 210

Online price:

Available in 5-7 working days.

Application
- Metrisches Gewinde
- Grundlöcher
- Max. Bohrtiefe 3xD
- Für universelle Anwendung in nahezu allen Werkstoffen

Execution
  • Für den Einsatz in CNC-gesteuerten Maschinen ausgelegt.
  • Erhöhte Toleranz für mehr Standweg in abrasiven oder klemmenden Werkstoffen.
  • Konisch abgesetztes Führungsgewinde
  • Mit axialer Innenkühlung
  • Längere Nuten
  • DIN-Anschnitt Form C (2-3 Gänge)
  • HSSE-PM GLT-1


Brand: EMUGE
Material to be processed: Universal use
Thread type x nominal diameter: M24
Max. thread depth: 3xD
Thread dimension: M24
Pitch: 3,00 mm
Cutting material: HSSE-PM
Surface: TiAlN plus
Hole type: Blind hole ≤ 3xD
Tolerance of screw taps (Tol.): 6HX
Lead angle shape: C
Length: 160 mm
Cutting edge length: 30 mm
Core hole diameter: 21,00 mm
Shank diameter: 18,0 mm
Shank square: 14,5 mm
Thread type: Metric thread
Type: GLT-1
Twist angle: 45° (right)
DIN: 376
Coolant supply: Internal axial
Nominal diameter: 24 mm
Shank style: Cylindrical with square drive
Cutting direction: Right-hand cutting

Manufacturer part no.: C581A601.0124

Product Datasheet Datasheet cutting values
