ATORN screw tap HSSE-PM ULTRA HL B 376 0° M16 2 ISO2 3xD CNC

ATORN screw tap HSSE-PM ULTRA HL B 376 0° M16 2 ISO2 3xD CNC

ATORN screw tap HSSE-PM ULTRA HL B 376 0° M16 2 ISO2 3xD CNC
Item no: 1014347 111

Online price:

Still in stock: 8

Application
For manufacturing metric threads on CNC or conventional machines in through holes in steel, stainless steel, non-ferrous metal, cast iron and special alloy material groups up to -1200 N/mm².

Advantage
  • Universal application for maximum flexibility
  • Innovative cutter geometry ensures high process reliability even in difficult machining conditions


Brand: ATORN
Material to be processed: Universal use
Thread type: Metric thread
Thread type x nominal diameter: M16
Tolerance of screw taps (Tol.): ISO 2X (6HX)
Hole type: Clearance hole ≤ 3xD
Lead angle shape: B
Length: 110 mm
Cutting material: HSSE-PM
Surface: ULTRA HL
Pitch: 2 mm
Twist angle: 0°
DIN: 376
Shank diameter: 12 mm
Application type/machine type: CNC | Conventional
Core hole diameter: 14 mm
Type: UNI MAX 45HL Speed
Coolant supply: External
Shank square: 9 mm
Cutting speed (steel 1000) suitability (ISO P 1000 N/mm²): 1
Cutting speed (steel 1300) suitability (ISO P 1300 N/mm²): 1
Overall stainless steel suitability (ISO M): 1
fitness not iron total (ISO N): 2
fitness Titan/Nickel/Super total (ISO S): 1
Cutting speed (cast) suitability (ISO K): 1
Cutting speed (hard 55) suitability (ISO H 55HRC): 3
Cutting speed (hard 65) suitability (ISO H 65HRC): 3

ATORN-No.: 12280011

EAN no.: 4050293424454

Product Datasheet Datasheet cutting values
