Through hole screw tap M DIN 371 shape B 1.5xD HSS-E M2.5

Through hole screw tap M DIN 371 shape B 1.5xD HSS-E M2.5

Through hole screw tap M DIN 371 shape B 1.5xD HSS-E M2.5
Item no: 1014302 107

Online price:

Still in stock: 4

Application
Metric thread
Through holes
Max. drilling depth 1.5xD
Steels up to 700 N/mm2

Execution
  • Spiral point
  • M1.2 tolerance field ISO 1 (4H)


Brand: LIZZARD
Material to be processed: Steel
Thread type x nominal diameter: M2.5
Max. thread depth: 1.5xD
Thread dimension: M2.5
Pitch: 0,45 mm
Cutting material: HSSE
Surface: Uncoated
Hole type: Clearance hole ≤ 2xD
Tolerance of screw taps (Tol.): 6H
Lead angle shape: B
Length: 50 mm
Cutting edge length: 9 mm
Core hole diameter: 2,05 mm
Shank diameter: 2,8 mm
Shank square: 2,1 mm
Thread type: Metric thread
Twist angle: 0°
DIN: 371
Coolant supply: External
Nominal diameter: 2,5 mm
Shank style: Cylindrical with square drive
Cutting direction: Right-hand cutting

Versions
