Prec. cntrsink dr. 90° HSS-E Alunit w/ 3 clamp surf., uneven pitch dia. 20.5 mm

Prec. cntrsink dr. 90° HSS-E Alunit w/ 3 clamp surf., uneven pitch dia. 20.5 mm

Prec. cntrsink dr. 90° HSS-E Alunit w/ 3 clamp surf., uneven pitch dia. 20.5 mm
Item no: 1012263 205

Online price:

Available for immediate delivery

Application
For universal use up to 1300 N/mm²

Execution
  • For exact deburring and conical countersink cuts.
  • Special geometry with uneven pitch
  • Extremely smooth multi-layer Alunit coating for a long service life

Advantage
  • Maximum smoothness
  • Chatter-free running and optimum tool life


Brand: LIZZARD
Material to be processed: Universal use
Countersink angle: 90 Degree
Spot-facer diameter: 20,5 mm
Tip diameter: 3,5 mm
Cutting material: HSSE
Surface: TiAlN plus
Number of cutting edges: 3
Tool holding device: Parallel shank with three tightening surfaces
Shank diameter: 10 mm
Length: 63 mm
DIN: 335
Coolant supply: External
Type: c
