Shelf trolley grid walls 5 shelves load 750 kg load. surf. 1200x780 mm RAL 5007

Shelf trolley grid walls 5 shelves load 750 kg load. surf. 1200x780 mm RAL 5007

Shelf trolley grid walls 5 shelves load 750 kg load. surf. 1200x780 mm RAL 5007
Video
Item no: 1081709 202

Online price:

Availability on demand

Application
For the safe transport and storage of materials and goods.

Execution
  • Angular steel structure completely welded with tubular push handle
  • Front walls, 1 long side and roof made from wire grid (40 x 40 x 4 mm)
  • With double winged door made of angular steel with welded in wire grid
  • Double winged door with vertical locking rod with swivelling lever and cylinder lock
  • 1 fixed and 4 loose shelves
  • Made of rigid sandwich plates
  • Clear floor distance 280 mm
  • With vertical locking rod

Advantage
Convenient total stop included

Delivery
Assembled


Brand: FETRA
Loading surface size: 1200 x 780 mm
Load-carrying capacity: 750 kg
Length x width x height: 1370 x 845 x 1792 mm
Loading surface height: 292 mm | 582 mm | 882 mm | 1182 mm | 1482 mm
Material of loading surface: Wood
Number of loading surfaces: 5 PCS
Height: 1792 mm
Number of fixed rollers: 2 PCS
Number of steering rollers: 2 PCS
With wheel lock: Totalstop
Wheel width: 40 mm
Wheel diameter: 200 mm
Material of wheel: TPE
Colour: Brilliant blue RAL 5007
Surface: Powder-coated
Material of wall: Wire mesh
Design: With mesh panels on three sides and doors
EN standard: 1757-3
Length: 1370 mm
Loading surface length: 1200 mm
Loading surface width: 780 mm
Width: 845 mm

Manufacturer part no.: 5393

EAN no.: 4017976019178

Product Datasheet
