Chain hoist Yalelift 360, one chain str. sh/stl hsg, max. 1000kg, lift height 3m

Chain hoist Yalelift 360, one chain str. sh/stl hsg, max. 1000kg, lift height 3m

Chain hoist Yalelift 360, one chain str. sh/stl hsg, max. 1000kg, lift height 3m
Item no: 1080120 105

Online price:

Availability on demand

Application
The 360° rotating hand chain guide enables the operator to operate the device from all directions with no further need to work in the direct hazard zone. This results in increased safety through greater location flexibility.

Execution
  • Robust sheet-steel housing
  • Encapsulated ball bearings and slide bushings
  • Surface-protected round steel chain
  • The brake system produces less noise and wear than conventional brakes
  • 1 load-bearing chain strand

Notes
All models are also available in explosion-protected design. Larger load capacities deliverable on request.

Brand: YALE
Load-carrying capacity: 1000 kg
Nominal chain thickness: 18 mm
Chain diameter: 6 mm
Stroke force at nominal load: 30 daN
Lift height every 1 m hand chain is uncoiled: 20 mm
Lift height: 3000 mm
Min. hook spacing: 335 mm
Number of load chains: 1 PCS
Weight: 13 kg
EN standard: 818-7

Manufacturer part no.: N04700110

EAN no.: 4025092075190

Product Datasheet
