T6-600 electrical tester with FieldSense technology 600 V

T6-600 electrical tester with FieldSense technology 600 V

T6-600 electrical tester with FieldSense technology 600 V
Item no: 1062388 101

Online price:

Still in stock: 3

Application
Zur Messung von Elektroinstallationen und im Service.

Execution
  • HOLD button freezes measured values on the display to make work easier
  • Easy-to-read display with backlight
  • TPAK measuring instrument magnetic holder for convenient, hands-free operation
  • Voltage measurement without measuring leads
    • The open current clamp allows you to measure AC voltages without making contact with live points using measuring leads (requires a capacitive path to earth, which in most applications is provided through the user. In some cases, the earth connection must be established using a measuring lead). Without opening the covers or removing screws on terminal blocks. For conductor cross-sections of up to 120 mm2 and currents of up to 200 A. Transforms the way you work
  • Safer. Faster. Easier

Delivery
Electrical tester
Connected measuring leads with removable 4 mm protective probe caps
User documentation


Brand: FLUKE
Min./max. test voltage (DC): 0 V/DC-600 V/DC
Min./max. test voltage (AC): 0 V/AC-600 V/AC
Min./max. alternating current of measuring range: 0 A-200 A
Min./max. electrical-resistance measuring range: 0 Ohm-2000 Ohm
Measuring procedure: AC+DC
Overvoltage protection category: CAT III/600 V
Length x width x height: 61.1 x 259.3 x 43.8 mm
Max. collet opening: 17,8 mm
Display: Digital
EN standard: 61010-1 (VDE 0411-1)
Height: 43,8 mm
Length: 61,1 mm
Width: 259,3 mm
Battery designation: 1.5 V LR6 AA
Max. alternating current of measuring range: 200 A
Max. test voltage (AC): 600 V/AC
Max. test voltage (DC): 600 V/DC
Min. alternating current of measuring range: 0 A
Min. test voltage (AC): 0 V/AC
Min. test voltage (DC): 0 V/DC
Number of rechargeable batteries/batteries: 2 PCS

Manufacturer part no.: 4910322

EAN no.: 95969854108

Product Datasheet
