Articulated hook wrench with lug and suspension hole for nuts dia. 90-155 mm

Articulated hook wrench with lug and suspension hole for nuts dia. 90-155 mm

Articulated hook wrench with lug and suspension hole for nuts dia. 90-155 mm
Item no: 1050659 104

Online price:

Available for immediate delivery

Application
For DIN 1804 grooved nuts and DIN 981 roller bearing nuts.

Execution
  • Industrial design
  • With nose and hanging hole
  • Hardened special steel with black oxide finish

Advantage
  • Longer shank provides greater torque
  • Extended joint hook ensures full-surface gripping and safe use
  • Reinforced rivet extends service life and enables greater force transmission, especially with smaller sizes


Brand: AMF
Suitable for nut type: Bearing nut DIN 981 | Slotted nut DIN 1804
Suitable for min./max. nut male thread size (Für Mutter-Außen-Ø min./max.): 90-155 mm
Thickness: 7 mm
Length: 335 mm
Surface: Burnished
Suitable for min. nut male thread size: 90 mm
Suitable for nut male thread size: 155 mm

Manufacturer part no.: 51672

EAN no.: 4020772051679

Product Datasheet
