Conical washer DIN 6319 G for screws M 20, stamped, pressed and tempered

Conical washer DIN 6319 G for screws M 20, stamped, pressed and tempered

Conical washer DIN 6319 G for screws M 20, stamped, pressed and tempered
Item no: 1027018 107

Online price:

Available in 6-8 working days.

Application
Suitable for clamping over slotted holes in clamps.

Execution
  • Steel
  • Heat treated to 350 + 80 HV30
  • Max. (kN) = maximum transferable static screw force

Notes
Spherical washers and conical washers are used to transmit clamping forces in cases where clamping elements need to be adapted to uneven clamping surfaces. Pairing spherical washers or hexagon nuts to DIN 6330 with conical washers enables the associated clamping bolt to be swivelled out by 3°.

Brand: AMF
Suitable for screw: M20
Tension force (max.): 117 kN
Internal diameter (d2): 23,2 mm
Outer diameter (d4): 50 mm
Height (h3): 8 mm
DIN: 6319
Design: Pierced | Tempered | Pressed
Taper angle: 120 Degree

Manufacturer part no.: 82032

EAN no.: 4020772082031

Product Datasheet
