HHW VDI holder DIN 69880 B3A-50X25X44

HHW VDI holder DIN 69880 B3A-50X25X44

HHW VDI holder DIN 69880 B3A-50X25X44
Item no: 1021950 116

Online price:

Available in 8-10 working days.

Application
For clamping standard and internally cooled insert holders

Execution
  • VDI chuck
  • With grub screw for setting the cooling only on the insert holder

Advantage
  • Cooling via ball nozzle and/or insert holder
  • External cooling with G1/8 hose
  • Coolant tightness up to 80 bar


Brand: LIZZARD
VDI mount diameter (VDI Aufnahmedurchmesser d1): 50 mm
Shaft height (h1): 25 mm
Overall width (l2): 44 mm
Overall length (b1): 85 mm
Length 2 (b2): 42,5 mm
Length 3 (b3): 12,5 mm
Width 2 (l1): 22 mm
Height (h3): 35 mm
Height 2 (h4): 30 mm
Height 3 (h6): 48 mm
Height 4 (h7): 42,5 mm

EAN no.: 4024496149124

Product Datasheet
Additional articles

Please select a button.

Spare Parts
Versions
loading
Keywords:

[Text nicht gefunden]

  • ATORN HPC drill and plunge mill, 11.7x26x35.3x83, T4, HB shank, ULTRA-coated
  •
    Extension lead 25/25 length 1 m
  •
