Boring bar mount shank dia. 30 mm bore dia. 10 mm shape E2 DIN 69880

Boring bar mount shank dia. 30 mm bore dia. 10 mm shape E2 DIN 69880

Boring bar mount shank dia. 30 mm bore dia. 10 mm shape E2 DIN 69880
Item no: 1021922 108

Online price:

Available in 8-10 working days.

Application
For mounting boring bars with straight shank.

Execution
  • Type E2, axial
  • With coolant supply via spray nozzles
  • 20MnCr5 hardened to 60 +/- 2 HRC
  • Completely burnished and all functional surfaces ground
  • With ball spray nozzle and threaded connector for tube fittings

Notes
Suitable for boring bars with internal cooling.

Brand: LIZZARD
VDI mount diameter (VDI Aufnahmedurchmesser d): 30 mm
Clamping diameter (Spanndurchmesser d1): 10 mm
Outer diameter (D1): 50 mm
Projecting length (l): 60 mm
Coolant supply: Inner cooling and spray nozzles
Collar diameter (D): 68 mm
Collar height (l1): 21 mm

EAN no.: 4024496066124
