Sealed prec. collet chuck dia. 12mm w/spray nozzle GERC32-HPDD/469E DxL=33x40mm

Sealed prec. collet chuck dia. 12mm w/spray nozzle GERC32-HPDD/469E DxL=33x40mm

Sealed prec. collet chuck dia. 12mm w/spray nozzle GERC32-HPDD/469E DxL=33x40mm
Item no: 1021569 105

Online price:

Available in 6-8 working days.

Execution
  • HPDD with seal for inner coolant supply (can be used up to 120 bar) and spray nozzle
  • With small concentricity and repetition 2 µm (for system tolerance 3 µm and with 3 x D maximum = 50 mm), clamp bridge h10
  • For ATORN precision collet chucks and Fahrion CentroP precision collet chucks
  • With FAHRION|Protect corrosion protection for longer service life
  • Surface super-finished for enhanced retention force
  • Only the nominal dimension can be clamped (straight shank with h8)

Advantage
  • Greater concentricity extends tool service life
  • Collet chucks do not need to be replaced as often or can be used for longer for specific applications


Brand: FAHRION
Collet type: 469E GERC32-HPDD
Clamping diameter (d): 12,0 mm
Outer diameter (D): 32,7 mm
Length (L): 40,0 mm
Coolant supply: Inner cooling and spray nozzles
Clamping bypass: 0,0 mm
ISO: 15488
Max. concentricity: 0,003 mm

Manufacturer part no.: 22645

EAN no.: 4054631170973

Product Datasheet
Versions
loading
Keywords:

You might also be interested in this

  • ATORN collet ER32 HP dia. 7.0 mm (7.0-6.5 mm) concentricity 5 µm
  •
    Sealed prec. collet chuck dia. 10mm w/spray nozzle GERC25-HPDD/429E DxL=26x34mm
  •
    Sealed prec. collet chuck dia. 12mm w/spray nozzle GERC25-HPDD/429E DxL=26x34mm
  •
    LIZZARD Spannzange ER 16 HP Ø 9,0 Gummi abgedichtet Rundlauf 0,005 mm
  •
    Sealed prec. collet chuck dia. 14mm w/spray nozzle GERC25-HPDD/429E DxL=26x34mm
  •
    ATORN collet ER16 HP dia. 8.5 mm (8.5-8.0 mm) concentricity 5 µm
  •
    Sealed prec. collet chuck dia. 14mm w/spray nozzle GERC32-HPDD/469E DxL=33x40mm
  •
    LIZZARD Spannzange ER 32 HP Ø 13,5 metallisch abgedichtet Rundlauf 0,005 mm
  •
    Sealed prec. collet chuck dia. 8mm w/spray nozzle GERC16-HPDD/425E DxL=17x27.5mm
  •
    Depth probe TMT 120 for measuring probe cat. no. 35092 101-102
  •
