Precision collet chuck GERC 25-B/430 E hole 3.0 mm

Precision collet chuck GERC 25-B/430 E hole 3.0 mm

Precision collet chuck GERC 25-B/430 E hole 3.0 mm
Item no: 1021537 205

Online price:

Available in 6-8 working days.

Application
For clamping tools with straight shanks.

Execution
  • For ATORN precision collet chucks and Fahrion CentroP precision collet chucks
  • With FAHRION|Protect corrosion protection for longer service life
  • Surface super-finished for enhanced retention force

Advantage
  • Collet chucks do not need to be replaced as often or can be used for longer for specific applications
  • Greater concentricity extends tool service life

Notes
For plastic collet chuck boxes, see AQURADO storage system, art. no. 1084134.
The clamping bridge is up to 1 mm smaller in each case, e.g. 9-8 mm, except in the case of 1-mm and 1.5-mm collet chucks (then only 0.5 mm).

Brand: FAHRION
Clamping diameter (d): 3,0 mm
Collet type: 430E GERC25-B
Outer diameter (D): 26,0 mm
Length (L): 34,0 mm
Clamping bypass: 1,0 mm
DIN: 6499
Form: B
Max. concentricity: 0,005 mm

Manufacturer part no.: 0430E3RD GER25-B (FM4950-B)

EAN no.: 4054631180231

Product Datasheet
