Brand: ATORN
Shape of indexable insert ISO: C
Clearance angle of indexable insert ISO: C
Tolerance class of indexable insert ISO: M
Indexable insert type ISO: T
Size of indexable insert ISO: 12
Thickness of indexable insert ISO: 04
Corner radius of indexable insert ISO: 04
Carbide type area ISO: M | S
Machining conditions for indexable insert: Medium
Carbide type ISO: M15 | M30 | S15 | S30
Carbide type: ACM25T-1
ISO-Code Rotating: CCMT 120404
Material to be processed: Stainless steel | Special alloy
min./max. ap: 0.3-3.6 mm
f min./max.: 0.09-0.27 mm/U
Materials group: M (primary application) | S (secondary application)
f min.: 0,09 mm/r
max. f: 0,27 mm/r
max. ap: 3,6 mm
min. ap: 0,3 mm
Supply type: Smoothing
Chip breaker code: MM2
Min./max. Vc in stainless steel: 55-230 m/min
Min./max. Vc in special alloys: 25-145 m/min

ATORN-No.: 12350545

EAN no.: 4066107026646

Product Datasheet Datasheet cutting values
