ATORN boring bar, positive, with internal cooling A16M SVVCR11

ATORN boring bar, positive, with internal cooling A16M SVVCR11

ATORN boring bar, positive, with internal cooling A16M SVVCR11
Item no: 1018514 104

Online price:

Still in stock: 1

Application
For longitudinal and copy turning with DC indexable insert 35°

Execution
Precision-made boring bar, steel, with internal cooling, type V, pitch angle 72.5°, tip angle 35°, clearance angle 7°

Advantage
  • very slim geometry, optimised for contour turning work
  • positive body geometry ensures low cutting forces


Brand: ATORN
ISO name: A 16M SVVC R/L 11
Min. bore diameter (D min.): 23 mm
Shank diameter (d): 16 mm
Cutting edge height (h1): 9,5 mm
Clearance length (l2): 40 mm
Length (l1): 150 mm
Clamping surface height (h): 15 mm
Suitable for indexable inserts (ISO): VC.. 1103..
Tool design: Right
DIN: 8024

ATORN-No.: 12232454

EAN no.: 4050293561968

Product Datasheet
