ATORN end mill for ind. inserts IC T=3 20.0 x 90mm shaft DIN =20.0mm DIN 1835B

ATORN end mill for ind. inserts IC T=3 20.0 x 90mm shaft DIN =20.0mm DIN 1835B

ATORN end mill for ind. inserts IC T=3 20.0 x 90mm shaft DIN =20.0mm DIN 1835B
Item no: 1017505 111

Online price:

Still in stock: 2

Application
For universal use in all materials.

Execution
  • With Weldon shank
  • Wear-resistant, nickel-plated version
  • Internal cooling
  • Clamping screw tightening torque (indexable insert) M2.5 = 1.2 Nm


Brand: ATORN
Cutting edge diameter (D): 20 mm
Clearance length (L2): 25 mm
Length (L1): 90 mm
Shank diameter (d): 20 mm
max. ap: 9,3 mm
Number of cutting edges: 3 PCS
Suitable indexable insert no. (WSP Typ): 21
Suitable indexable insert no. (WSP Typ): 22

ATORN-No.: 11117200

EAN no.: 4050293113327

Product Datasheet
