ATORN SC radius cutter long TiAlSiN 10x12x100 mm radius 5 mm

ATORN SC radius cutter long TiAlSiN 10x12x100 mm radius 5 mm

ATORN SC radius cutter long TiAlSiN 10x12x100 mm radius 5 mm
Item no: 1016793 119

Online price:

Available in 6-8 working days.

Application
Radius milling cutter, long design, for machining materials up to 65 HRC, e.g. in dip cutting and mould construction.

Execution
  • Cutting material, Ultra Micro fine grain
  • cutting edge finish
  • HA shaft in line with DIN 6535
  • Clearance
  • type H
  • With RockTec PRO coating
  • Radius tolerance = +/- 0.005 mm

Advantage
  • optimum chip removal and temperature resistance
  • Optimised geometry for machining hard materials
  • maximum service life thanks to RockTec PRO coating


Brand: ATORN
Cutting material: SC
Surface: RockTec PRO
Type: H
Number of cutting edges (Z): 2 PCS
Twist angle: 30°
Tool holding device: HA parallel shank
Construction length: Extra long
Cutting edge diameter: 10 mm
Cutting edge length: 12 mm
Length: 100 mm
Shank diameter: 10 mm
fz hard 65 HRC: 0,062 mm

ATORN-No.: 11264103

EAN no.: 4050293653328

Product Datasheet Datasheet cutting values
