Die, right-cutting DIN EN 22568 with spiral point HSS M 10

Die, right-cutting DIN EN 22568 with spiral point HSS M 10

Die, right-cutting DIN EN 22568 with spiral point HSS M 10
Item no: 1015206 222

Online price:

Still in stock: 5

Application
For standard metric ISO thread DIN 13. For normally machinable materials up to approx. 850 N/mm².

Execution
  • Closed (pre-slotted)
  • With spiral point for ultra-easy, clean cuts and improved surface quality
  • Chips flow forward in the cutting direction, no clogging of the chip holes
  • Tolerance field 6g
  • Chamfer approx. 1.1/2 turns


Brand: EMUGE
Thread type: Metric thread
Cutting material: HSS
Tolerance of dies: 6 g
Thread type x nominal diameter: M10
Pitch: 1,5 mm
Outer diameter: 30 mm
Height: 11 mm
Cutting direction: Right-hand cutting
EN standard: 22568
Nominal diameter: 10 mm
Die mount diameter: 30 mm
Material to be processed: Steel

Manufacturer part no.: D500
