Through hole and blind hole screw tap M DIN 371 shape A 2xD SC-TiAlN+C M4

Through hole and blind hole screw tap M DIN 371 shape A 2xD SC-TiAlN+C M4

Through hole and blind hole screw tap M DIN 371 shape A 2xD SC-TiAlN+C M4
Item no: 1014355 104

Online price:

Available for immediate delivery

Application
- Metric thread
- Through and blind holes
- Max. drilling depth 3xD
- Up to HRC 60

Execution
  • Tolerance range 6H
  • DIN type C (2-3 chamfer threads)
  • DIN 371/376
  • SC TiAlN+C

Notes
For very hard steels, we recommend drilling the core hole larger by 0.1 to 0.3 mm in deviation from the DIN standard.

Brand: ATORN
Material to be processed: Hard material | Hardened steel
Thread type: Metric thread
Thread dimension: M4
Thread type x nominal diameter: M4
Tolerance of screw taps (Tol.): 6H
Hole type: Clearance/blind hole ≤ 2xD
Lead angle shape: C
Length: 63 mm
Cutting material: SC
Surface: TiAlN plus
Pitch: 0,7 mm
Twist angle: 0°
DIN: 371
Shank diameter: 4,5 mm
Application type/machine type: CNC | Conventional
Core hole diameter: 3,30 mm
Coolant supply: Internal axial
Shank square: 3,4 mm
Cutting speed (steel 1000) suitability (ISO P 1000 N/mm²): 3
Cutting speed (steel 1300) suitability (ISO P 1300 N/mm²): 3
Overall stainless steel suitability (ISO M): 3
fitness not iron total (ISO N): 3
fitness Titan/Nickel/Super total (ISO S): 3
Cutting speed (cast) suitability (ISO K): 3
Cutting speed (hard 55) suitability (ISO H 55HRC): 1
Cutting speed (hard 65) suitability (ISO H 65HRC): 1

ATORN-No.: 11290226

EAN no.: 4050293132687

Product Datasheet Datasheet cutting values
