Machine reamer DIN 212 cyl. spiral-fluted HSS-E TiN 12 mm

Machine reamer DIN 212 cyl. spiral-fluted HSS-E TiN 12 mm

Machine reamer DIN 212 cyl. spiral-fluted HSS-E TiN 12 mm
Item no: 1013507 120

Online price:

Still in stock: 5

Application
For through holes and blind holes.

Execution
  • With straight shank (without square drive)
  • Right-cutting
  • Spiral-fluted
  • Anticlockwise spiral 7–8°
  • Short 45° chamfer
  • Even number of teeth
  • Unequal tooth pitch (prevents chatter marks and hole distortion)
  • HSS-E/TiN coated

Notes
Intermediate dimensions deliverable on request.

Brand: LIZZARD
Cutting edge diameter: 12 mm
Tolerance of fit: H7
Groove type: Left-hand twist, 7-8°
Length: 151 mm
Cutting edge length: 44 mm
Tool holding device: Cylinder shank
Shank style: Cylindrical
Cutting material: HSSE
Shank diameter: 10,0 mm
f steel 1000: 0,15 mm/r
Coolant supply: External
Cutting direction: Right-hand cutting
DIN: 212
Surface: TiN
