ATORN SC NC reamer T=8 B 7-8° 16.0mm H7 x 170mm x 52mm HA sim. to DIN 8093

ATORN SC NC reamer T=8 B 7-8° 16.0mm H7 x 170mm x 52mm HA sim. to DIN 8093

ATORN SC NC reamer T=8 B 7-8° 16.0mm H7 x 170mm x 52mm HA sim. to DIN 8093
Item no: 1013502 255

Online price:

Still in stock: 5

Application
For producing H7 fit tolerances in through holes on NC machines up to 1300 N/mm².

Execution
7-8° left-hand spiral, type B

Advantage
good bore hole quality (dimensional tolerance, roundness, surface quality)


Brand: ATORN
Material to be processed: Universal use
Cutting material: SC
Tolerance of fit: H7
Groove type: Left-hand twist, 7-8°
Tool holding device: HA parallel shank
Surface: Uncoated
Cutting edge diameter: 16 mm
Length: 170 mm
Cutting edge length: 52 mm
Projecting length: 120 mm
Shank diameter: 14 mm
Number of cutting edges: 8 PCS
f steel 1300: 0,18 mm/r
DIN: 8093 similar

ATORN-No.: 10041960

EAN no.: 4050293005561

Product Datasheet Datasheet cutting values
