NC spotting drill, sol. carbide 142° TiAlSiN, dia. 5 mm x 120 mm HA shaft, long

NC spotting drill, sol. carbide 142° TiAlSiN, dia. 5 mm x 120 mm HA shaft, long

NC spotting drill, sol. carbide 142° TiAlSiN, dia. 5 mm x 120 mm HA shaft, long
Item no: 1010912 105

Online price:

Available in 5-7 working days.

Application
For 142° spot drilling for the following twist drills on CNC machines.

Execution
Spiral-fluted, extra long design

Advantage
  • Extra long design with precise point geometry and chisel edge that ensure geometrically accurate and process-reliable spot drilling, even with deeply recessed or hard-to-access components
  • The follow-on tool does not run off centre
  • Precise gauge thanks to special point thinning of the chisel edge
  • Maximal service life thanks to innovative coating

Notes
Diameter less than 6 mm with HA shaft

Brand: ATORN
Material to be processed: Universal use
Angle of the tip: 142 Degree
Cutting material: SC
Surface: TiAlSiN
Tool holding device: HA parallel shank
Cutting edge diameter: 5 mm
Cutting edge length: 14 mm
Length: 120 mm
f steel 1300: 0,12 mm/r

ATORN-No.: 10916175

EAN no.: 4050293695908

Product Datasheet Datasheet cutting values
