ATORN drill bit for machine tap, solid carbide TiN M10 8.5mm

ATORN drill bit for machine tap, solid carbide TiN M10 8.5mm

ATORN drill bit for machine tap, solid carbide TiN M10 8.5mm
Item no: 1003141 692

Online price:

Available in 6-8 working days.

Application
For drilling out broken-off screw taps (HSS, HSSE, HSSE PM) up to a hardness of 65 HRC using bench-type or column-type drills, wet or dry machining at a rotation speed of 1000-2000 rpm in hand-feed or for wet machining on CNC machines at a rotation speed of 1400-2400 rpm and a feed rate of 0.03-0.06 per revolution. The drill bit has a service life of 3 to 5 screw taps.

Execution
Solid carbide-TiN drill bit, with three cutting edges

Advantage
  • User-friendly and efficient removal of screw taps saves time and money.
  • Innovative cutting geometry ensures high process reliability and a long service life.


Brand: ATORN
Material to be processed: Hard material | Hardened steel
Cutting material: SC
Suitable for screw thread: M10
Cutting edge diameter: 8,5 mm
Chip flute length: 25 mm
Length: 80 mm
Shank diameter: 9 mm
DIN: 374

ATORN-No.: 12040006

EAN no.: 4050293349023

Product Datasheet
